V-TAC Deye Single Phase Hybrid On-Grid/Off-Grid 3.6kW WIFI Photovoltaic Inverter

The V-TAC Hybrid Inverter SKU 11725 , Single-phase 3.6kW Double MPPT , is an electronic device that allows you to convert the direct current supplied by photovoltaic solar panels into alternating current, with single-phase output suitable for consumption in homes or commercial premises.
It comes complete with accessories : Current Transformer (TA), 2 pairs of MC4 Solar Connectors, RJ45 cable and WiFi module for remote monitoring.

It is equipped with a color LCD Touch Screen that allows you to quickly interact with the inverter parameters and to control by default the production, the battery charge status, consumption, and the network. Integrated Zero Emission Function, so it is possible to set NOT to export energy to the network, thus preventing its sale. Heat dissipation occurs via radiators, thus ensuring low noise. Equipped with charge/discharge protection. The degree of protection is IP65 , so it can also be used outdoors , even under prolonged rain.

Advantages of a Deye Hybrid Inverter

This inverter is defined as hybrid as it can operate both connected (On-Grid) and disconnected (Off-Grid) from the electrical grid .
The hybrid inverter offers the option of connecting appropriate storage batteries .
Choosing a hybrid inverter is optimal because it is possible to store excess energy that is not consumed during the daytime hours, and then use it during the night hours.
A correctly sized photovoltaic system can therefore make consumption independent (not purchased) from the electricity grid .

Remote Control App

Thanks to the included WiFi module, it is possible to monitor the photovoltaic system and control consumption remotely , via the Apps:

• Private Use: SOLARMAN Smart (Download): iOS / Android / Web App ), suitable for domestic use, offers with a free license the possibility of remotely controlling production, consumption and battery status (real time and historical);
• Business Use: SOLARMAN Business (Download): iOS / Android / Web App ), suitable for Electricians and Photovoltaic System Managers, offers with a free license the possibility of having a centralized view of all the systems created or shared and of issuing the authorizations for access to the system to the end user or other company units.
  Once logged in, to add one or more systems follow the wizard for initializing a new system, + button.

Accessories included

• 2 x 11413 Pair of MC4 Solar Connectors for Photovoltaic Cables
• 1 x 11530 2.4GHz WiFi Antenna Module Data Logger Remote Control Inverter Deye IP65
• 1 x 11531 Current Transformer TA/CT for Current Measurement Deye Compatibility

• SKU 11725
• Family Code SUN-3.6K-SG03LP1-EU
• V-TAC brand
• 10 year warranty
• Degree of Protection IP65
• Size 330x580x232mm
• Maximum AC power 3.6 kW
• Producer Deye
• Single Phase Electrical System
• Inverter output 230V L+N+PE
• Maximum input power 4.68 kW
• Maximum input voltage for MPPT 500 V
• Minimum operating voltage 150 V
• MPPT voltage range 300 - 425 V
• MPPT nominal voltage 370 V
• Number of MPPT trackers 2
• Maximum current for MPPT 13 A
• Maximum output current 18A
• Network frequency 50 / 60 Hz
• Mains voltage 220/230 V
• Power factor 0.8 lagging / 0.8 leading
• THDi <3%
• Maximum efficiency 97.6%
• MPPT efficiency 99.9%
• RS485 / RS232 / CAN communication
• Passive Cooling
• Noise <30dB
• Maximum operating altitude 2000 m
• Relative humidity 0 - 95 %
• Night time power consumption <3W
• Strings for MPPT 1/1
• Starting voltage 125V
• MPPT short circuit current 17 A
• 3 Stage Charging Curve / Equalization
• External temperature sensor Yes
• Charging Strategy for Lithium Ion Battery Self-adaptation to BMS
• Operating Temperature -40 - 60 °C
• Installation Type Wall mounted
• Low Voltage (LV) Compatible Battery Architecture
• Compatible Battery Chemistry LFP (LiFePO4) / Lead-Acid
• Battery Voltage Range 40 - 60 V
• Maximum Charging Current 90A
• Maximum Discharge Current 90 A
• Integrated PV input lightning protection
• Integrated Anti-islanding Protection
• Integrated PV string input reverse polarity protection
• Integrated insulation resistance detection
• Integrated residual current monitoring unit
• Built-in output overcurrent protection
• Output short circuit protection Built-in
• Built-in output overvoltage protection
• DC Type II / AC Type II Surge Protection
• Network regulation VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727, RD1699: 2011, XP C15-712-3, CEI 0-21
• Safety standards IEC62109-1, IEC62109-2
• EMC EN61000-6-1, EN61000-6-3
