Nvr Ip Poe 32 Channels H.265 4K 8Mp 160Mbps Video Analysis Dahua

New Dahua 4K Ultra HD Professional IP NVR Series for Surveillance - 32 IP Channels with Resolution up to 8MP , Supports H.265 Video Compression . HDMI/ VGA Video Outputs, Onvif Support, Max 2 3.5" SATA HDD , 2 USB Ports, Cloud Support P2P Alarm & Audio Inputs/Outputs. Video Analysis, Facial Recognition, People Counting . NVR4232-4KS2-L

Up to 8MP resolution - H.265 / H.264 Video Compression - 160mbps input bandwidth - Alarm & Audio Inputs/Outputs - Supports Video Analysis and Face Detection - SMD Plus ONVIF Support - Hard Disk NOT included - 24 months warranty

4K technology (also called ULTRA HD ) is one of the latest innovations in the field of high definition viewing. 4K corresponds to the resolution of 4 Full-HD, so 3840 X 2160!
Already used in the consumer electronics sector, it is finally arriving in the world of security. The new generation of DAHUA devices, in fact, allows the support of cameras up to 12MPX on H265 standard, the new video compression that allows savings of up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image with its maximum detail

• SYSTEM
• Main Processor Industrial-grade embedded processor
• Operating System Embedded Linux
• Operation Interface Web/operating in local GUI
• Perimeter Protection by Camera
• Performance 8 channels
• AI Search Search for pictures by channel, time and event type
• Face Detection by Camera
• Performance 4 channels
• Face Attributes 6 attributes: Gender, age, glasses, expression, mouth mask, and beard
• AI Search Search for pictures by channel, time and face attributes
• SMD Plus by Camera
• Performance
• 12 channels
• AI Search Search by target classification (human, vehicle)
• Video
• Access Channel 32
• Network Bandwidth Access: 160 Mbps; Storage: 128Mbps; Forward: 48Mbps
• Resolution 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; Q1
• Decoding Capability 8 × 1080p@30 fps
• Video Output 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
• Multi-screen Display 1, 4, 8, 9, 16, 25, 32 views
• Third-party Camera Access ONVIF; RTSP
• Compression
• Video Smart H.265/H.265/Smart H.264/H.264/MJPEG
• Audio PCM/G711A/G711U/G726/AAC
• Network
• Network Protocol HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
• Mobile Phone Access Android; iOS
• Interoperability ONVIF(profile T/S/G); CGI; SDK
• Chrome Browser; IE9 or later; firefox
• Record Playback
• Multi-channel Playback Up to 16 channels for playback
• Record Mode Manual record; alarm recording; SMD recording; smart recording
• Storage Local HDD; network
• Backup USB storage device
• Playback Function 1. Play/pause/stop/slow/quick/backward/by frame
• 2. Full screen, backup (video clip/file), partial zoom in, and audio on/of
• Disk Group Yes
• Alarm
• General Alarm Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
• Anomaly Alarm Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
• Intelligent Alarm Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms
• Alarm Linkage Recording, snapshot, local external alarm output, audio, buzzer, log, preset, and email
• External Port
• Audio Input 1 × RCA input
• Audio Output 1 × RCA output
• HDD 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
• Alarm Input 4
• AlarmOutput 2
• USB 2 (1 × front USB2.0; 1 × back USB2.0)
• HDMI 1 (supports up to 4K resolution output)
• VGA 1
• Network 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port
• General Parameter
• Power Supply 12V DC, 4A
• Power Consumption < 5.6 W (HDD not included, idling)
• Net Weight 1.5 kg (3.31 lb)
• Gross Weight 2.6 kg (5.73 lb)
• Product Dimensions 375.0 mm × 282.9 mm x 53.0 mm (14.76" × 11.14" × 2.09") (W × L × H)
• Package Dimensions 433 mm × 140 mm × 363 mm (17.05" × 5.51" × 14.29") (W × L × H)
• Operating Conditions –10 °C to +55 °C (+10 °F to +131 °F)
• Storage Conditions 0 °C to +40 °C (32 °F to 104 °F)
• Operating Humidity 10℅~93℅
• Storage Humidity 30%~85%
• Operating Altitude 3000 m (9842.52 ft)
• Installation Desktop/Rack mount
• Certifications CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4 FCC: Part 15 Subpart B
