Dahua NVR 8 IP Channels 4K Ultra-HD 12 Mpx 320 Mbps H.265 Pro Series

New Dahua 4K Ultra HD Professional IP NVR Series for Surveillance - 8 IP Channels with Resolution up to 12Mpx, Supports H.265 Video Compression, Up to 320Mbps Broadband Input. HDMI/VGA Video Outputs, Support Onvif Vers. 2.4, Max 2 SATA 3.5" HDD, 2 USB Ports, Cloud P2P Support. Alarm Inputs/Outputs. Video Analysis. RS232 Port. NVR5208-4KS2-V2

4K technology (also called ULTRA HD ) is one of the latest innovations in the field of high definition viewing. 4K corresponds to the resolution of 4 Full-HD, so 3840 X 2160!
Already used in the consumer electronics sector, it is finally arriving in the world of security. The new generation of DAHUA devices, in fact, allows the support of cameras up to 12MPX on H265 standard, the new video compression that allows savings of up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image with its maximum detail.

The device can be used as edge storage, central storage or backup storage. Compatibility with third-party devices, ideal solution for surveillance systems even without VMS software. Open architecture for multi-user access and compatibility with ONVIF 2.4.

Perimeter protection (cameras): Automatic filtering of false alarms caused by animals, foliage movements, light effects, etc… which significantly increases the accuracy of the alarms.

Face Recognition (cameras): Real-time comparison of captured faces with those entered in the database. Different types of modes and alarms.

SMD Plus (cameras): Thanks to advanced algorithms, Dahua smart motion detection technology classifies targets that trigger motion detection and filters out irrelevant alarms.

ANPR (cameras): Automatic Number Plate Recognition: license plate reading (with ITC cameras).

Fisheye Dewarping: Solves the problem of distortion in panoramic view. The NVR offers various dewarping modes for different installations and configurations both live and playback.

People Counting (cameras): Using deep learning algorithms, Dahua People Counting technology tracks and processes people in motion, providing accurate statistics on the number of entries, exits and stays in certain areas. Together with the management platform, it is possible to generate annual, monthly, weekly and daily reports.

Behavioral Analysis (Cameras): 3D scenes and deep learning algorithms enable Dahua stereo analysis technology to detect falls, violence and other abnormal behaviors.

DMSS: The DMSS app is available for both iOS and Android and allows you to remotely manage your devices, view live video, receive push notifications and search for recordings anywhere, anytime.

DATA SHEET Dahua NVR5208-4KS2-V2

• 8 IP channels
• Smart H.265+/Smart H.264+/H.265/H.264/MJPEG; H.265
• Max 320 Mbps input bandwidth
• Resolution up to 24MP for live and playback
• 1 channel dewarping fisheye
• AI functions performed by cameras: perimeter protection, face detection and recognition, SMD Plus, video metadata, ANPR, people counting, behavioral analysis, crowds, heat maps
• Resolutions: 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080P, 1.3 MP, 720P, D1 etc…
• Decoding capacity: 8 channels@1080P (30 fps)
• Video outputs: 1 HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 /1 VGA: 1920×1080, 1280×1024, 1280×720
• Third parties. Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more
• Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (IP cameras, DVR, NVS, etc… Dahua), P2P
• Compatibility: ONVIF (profiles T, S and G), CGI, SDK
• HDD: 2 SATA III ports, up to 10TB per HDD. Maximum capacity may vary based on ambient temperature
• USB: 1 front USB 2.0 port, 1 rear USB 3.0 port
• HDMI: 1
• VGA: 1
• Dimensions: 375×282.4×53 mm
