Dahua NVR 32 IP Channels 4K Ultra-HD 12 Mpx 320Mbps H.265 Pro Series

New Dahua 4K Ultra HD Professional IP NVR Series for Surveillance - 32 IP Channels with Resolution up to 12Mpx, Supports H.265 Video Compression, Up to 320Mbps Broadband Input. HDMI/ VGA Video Outputs, Support Onvif Vers. 2.4, Max 2 3.5" SATA HDD , 2 USB Ports, P2P Cloud Support. Alarm Inputs/Outputs. Video Analysis. RS232 Port. NVR5232-4KS2-V2

Up to 12Mpx resolution - Up to 320Mbps broadband input - H.265 Video Compression Alarm Inputs/Outputs - Hard Disk NOT included! - HDMI/VGA - 2 USB - Onvif Version 2.4 Support - Cloud P2P

4K technology (also called ULTRA HD ) is one of the latest innovations in the field of high definition viewing. 4K corresponds to the resolution of 4 Full-HD, so 3840 X 2160!
Already used in the consumer electronics sector, it is finally arriving in the world of security. The new generation of DAHUA devices, in fact, allows the support of cameras up to 12MPX on H265 standard, the new video compression that allows savings of up to 50% compared to the previous H264. Thanks to the 4K output it is also possible to view (on a 4K monitor) the image with its maximum detail.

• SYSTEM
• Main Processor Quad-core embedded processor
• Operating System Embedded LINUX
• VIDEO&AUDIO
• IP Camera Input 32 channels
• Two-way talk 1 channel Input, 1 channel Output, RCA
• DISPLAY
• Interfaces 1 HDMI, 1 VGA
• Resolution HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024,1280 × 720, 1024 × 768
• VGA: 1920×1080, 1280×1024,1280×720, 1024×768
• Decoding Capability 16-ch@1080P(30fps)
• Multi-screen Display 1/4/8/9/16/25/36
• OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
• RECORDING
• Compression Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
• Resolution
• 12MP with 15fps, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P,1.3MP, 720P, D1, CIF with 30fps
• Bit Rate 16Kbps ~ 20Mbps Per Channel
• Recording Mode Manual, Schedule (Regular, MD(Motion Detection) ,Alarm, IVS), Stop
• Recording Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30sec, Post-record: 10 ~ 300 sec
• VIDEO DETECTION & ALARM
• Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, Snapshot, Buzzer and Screen Tips
• Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Alarm Input 4 Channel
• Relay Output 2 Channel
• PLAYBACK & BACKUP
• Playback Channel 1/4/9/16
• Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
• Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
• Backup Mode USB Device/Network/Internal SATA burner
• THIRD PARTY SUPPORT
• Third-party Support Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
• NETWORK
• Interface 1 RJ-45 Ports (10/100/1000Mbps)
• Network Functions
• HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
• Max User Access 128 users
• Smart Phone iPhone, iPad, Android
• Interoperability ONVIF 2.4, SDK, CGI
• HARD DISK
• Hard Disk 2 SATA III Ports, Up to 8 TB capacity for each HDD
• AUXILIARY INTERFACE
• Usb Interface 2 USB Ports (1 Rear USB 3.0, 1 Front USB 2.0)
• RS232 1 Port, for PC Communication and Keyboard
• RS485 1 Port, for PTZ Control
• GENERAL
• Single Power Supply, DC12V/4A
• Power Consumption <9.5W (Without HDD)
• Fan Smart fan, automatically adjust running speed
• Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
• Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
• Dimensions 1U, 375mm x 281.5mm x 56mm ;
• (14.8" x 11.1" x 2.2")
• Weight
• NET: 1.6kg (3.5 lb) (without HDD)
• GROSS: 3.2kg (7.1 lb) (without HDD))
• THERE IS
• EN55022, EN55024, EN50130-4, EN60950-1
• FCC Part 15 Subpart B, ANSI C63.4-2014
• UL UL 60950-1
