Dahua DVR 8 Channel Hybrid P2P Cloud 1080N 5In1 Ai 1U Wizsense Xvr4108Hs-I

Dahua XVR4108HS-I 8Ch channels HDCVI Analog 5IN1 XVR Video Recorder multiple CCTV standard management (HDCVI / AHD / HDTVI / PAL / IP) with resolution up to 1080N (960x1080N) and AI-Coding / H.265 + video compression. 1 HDMI, 1 VGA, 2 USB, RS485, support for 1 HDD SATA 3.5" Audio / Video (max 6TB). Supported functions: Perimeter Protection - SMD Plus / Smart Search / Smart Fan / Coax. Audio./ Cloud P2P.

XVR is the most effective solution to upgrade all old CCTV video surveillance systems, as it allows to integrate all new analog CCTV standards "HDCVI/HDTVI/AHD" in high definition, giving the possibility to install cameras even at long distances (800-1000M) using the traditional micro coaxial wiring used for the installation of analog CVBS cameras. Video recording is processed by a new video compression system identified as AI-Coding. Compared to H.265, the AI ​​codec can reduce up to 50% in bit rate and storage requirements without loss of decoding compatibility, providing clear details of objects, people and vehicles in the recording files.

WizSense is Dahua's revolutionary series of solutions powered by AI technologies such as independent chips and deep learning algorithms. WizSense devices accurately distinguish human and vehicle figures in the scene, focusing on the real targets of interest to eliminate false alarms and raise the level of intelligence. WizSense is based on AI chips and deep learning algorithm. It provides various functions that realize accurate alarms for people and vehicles, as well as rapid target search, maximizing resources to increase overall efficiency. It offers easy configuration, especially for SMD Plus which can be enabled with a single button. It facilitates customers' daily work and also empowers them to make better business decisions.

SMD Plus Technology, is the new evolutionary stage of Smart Motion Detection, a function that allows the XVR to distinguish human silhouettes and moving vehicles by effectively filtering insects, animals, rain, lights and foliage movement. SMD Plus uses an independent AI chip with deep-learning technology that gives it 95% accuracy. This video recorder supports Artificial Intelligence functions!

Thanks to this technology, Dahua guarantees private individuals and installers a simple, low-cost installation with surprising results and added value in the field of video surveillance. Video security system ideal for a wide range of applications: from companies to public administrations, from parks to institutional offices, from museums to airports, from villas to small condominiums etc...

Specifications

• Supported CCTV Technological Standards: CVBS/HDCVI/HDTVI/AHD + IP@ 6Mpx (Max. 2 IP - 32Mbps) ONVIF 16.12, CGI Conformant
• Supported HDCVI resolutions: On the first channel 1080N/720p@(1fps-25fps); on all other channels 1080N/720p@(1fps-15fps); 960H/D1/CIF@(1fps-25/30fps);
• Supported AHD Resolution: On the first channel 1080N/720p@(1fps-25fps); on all other channels 1080N/720p@(1fps-15fps); 960H/D1/CIF@(1fps-25/30fps);
• Supported HD-TVI resolution: On the first channel 1080N/720p@(1fps-25fps); on all other channels 1080N/720p@(1fps-15fps); 960H/D1/CIF@(1fps-25/30fps);
• Video signal transmission over long distances (800-1100M), using coaxial cable.
• Management from XVR via coax cable. OSD menu and PTZ movement of cameras.
• AI-Coding/H.265+/H.265/H.264+/H.264 dual-stream video compression.
• HDMI / VGA simultaneous video output (supports simultaneous output of video sources for VGA and HDMI).
• 1/4/8/9 channels (IP extension not active) or 1/4/8/9/16 (IP extension active), GRID interface and smart search
• Dahua PTZ Dome Camera 3D Intelligent Positioning - RS485 Port for Classic Analog PTZ.
• Supports 8 Inputs (BNC) + 1 RCA Audio Output (HDCVI only). Microphone input and output (Two-way talk) 1/1 RCA possible.
• Supports 1 SATA HDD up to 6TB, 2 USB ports (USB 2.0)
• Multiple network monitoring: Web viewer, CMS (DSS / Smart PSS) Smartphone (DMSS).
• New simplified and intelligent GUI (HDCVI 5.0 version); with Smart Fan / Coax. Audio / AI / Perimeter Protection and SMD Plus functions
• Support and program AI functions: SMD Plus perimeter protection, AI search, False Alarm FIlter.
• AI function programming on channels - 8Ch SMD Plus perimeter protection channels.
• Easy setup P2P QR scan with dedicated Dahua Cloud service.
• ONVIF Compliant Onvif Version 16.12, CGI Conformant

• STANDARD: AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
• VIDEO INPUTS: 8 BNC units
• VIDEO OUTPUTS:
• 1 HDMI unit
• 1 VGA unit
• AUDIO INPUTS:
• 1 unit - CINCH (RCA)
• 8 units - Support for audio via coaxial cable, HD-CVI only
• AUDIO OUTPUTS: 1 unit CINCH (RCA)
• IMAGE COMPRESSION METHOD: AI Coding / H.265+ / H.265 / H.264+ / H.264
• RECORDED IMAGE RESOLUTIONS:
• AHD / HD-CVI / HD-TVI :
• 1080N - 960 x 1080 ,
• 720p - 1280 x 720 ,
• CVBS :
• 960H - 960 x 576
• IP :
• max. 6 Mpx - 3072 x 2048
• RECORDING SPEED ADJUSTMENT:
• 6 Mpx IP @ 1 ... 25 fps - Only on IP camera
• 1080N/720p @ 1 ... 25 fps - Only on the first channel (1Ch)
• 1080N @ 1 ... 15 fps
• 720p @ 1 ... 15 fps
• 960H @ 1 ... 25 fps
• to be assigned to each channel
• OPERATION MODE: 8 x AHD / HD-CVI / HD-TVI / CVBS / IP + 2 x IP
• RECORDING MODE: Manual, Alarm, Motion Detection, Schedule, SMD Recording, Smart Recording.
• SUPPORTED HARD DRIVES: 1 x 6TB SATA
• BACKUP STORAGE ON EXTERNAL DEVICES: Save single frames and entire recordings to your USB drive
• SEARCH AND PLAYBACK OF RECORDINGS: Search recordings by time + timeline with recording type. Playback: forward, fast mode, slow mode, step
• Advanced search (with one-second precision)
• NETWORK FUNCTIONS: Client software and IE browser: live preview, recording playback and backup, partial configuration of recorder parameters
• MOBILE ACCESS: Port: 37777 or cloud access
• Android: Darmowa applikacja gDMSS Plus
• iOS (iPhone): Darmowa aplikacja iDMSS Plus
• ALARM INPUTS / OUTPUTS: No
• PTZ CONTROL: Speed ​​Dome IP Cameras
• HD-CVI PTZ coax compatible control
• RS-485 - PELCO-D/P
• MOTION DETECTION: Screen division into zones: 22 x 18 detection fields
• USB: 2 x USB 2.0 drives (1 x rear; 1 x front)
• MOUSE SUPPORT: Yes
• IR REMOTE CONTROL SUPPLIED: No
• POWER SUPPLY: 12 V DC / 1.5 A (power supply included)
• COLOR: Black
• WEIGHT: 0.99 kg
• DIMENSIONS: Compact 1U - 260.0 mm × 237.9 mm × 47.6 mm (10.24'' × 9.37'' × 1.87'')
• SUPPORTED LANGUAGES: Polish, English, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Hungarian, Italian
• COUNTRY OF ORIGIN: China
• MANUFACTURER / BRAND: DAHUA
