Dahua DVR 32 Hybrid Channels 4 Mpx Hdcvi Ahd Hdtvi Pal Xvr4232An-X

XVR (DVR/NVR) Penta-brid 1U 32CH channels 5IN1 multiple management CCTV standard: analog CVBS/HDCVI/HDTVI/AHD + IP@6Mpx - HD resolution in recording on the first channel 1080N/720p@25fps while for the remaining channels, recording at 1080N/720p@15fps. Possibility of managing IP cameras Max. 16 (64Mbps) Video Compression up to H.265+ / Smart Search / Smart Fan / Coax. Audio. Cloud P2P - ONVIF Standard Dahua XVR4232AN-X

XVR is the most effective solution to upgrade all old CCTV video surveillance systems, as it allows to integrate all new analog CCTV standards "HDCVI / HDTVI / AHD" in high definition, giving the possibility to install cameras even at long distances (800-1000M) using the traditional micro coaxial wiring used for the installation of analog CVBS cameras. Video recording is processed by a new video compression system identified as H.265 codec. This technology allows to save up to 50% on storage space and data traffic consumption in remote viewing, compared to the previous H.264 compression.

Note: It is also possible to use the UTP network cable associated with the Video Balun devices. Using the UTP network cable, the maximum video quality of analog CCTV cameras is not guaranteed. Furthermore, as in HDCVI technology, it is possible to use the coaxial or UTP connection cable to manage all the camera parameters from the XVR such as: OSD settings, PTZ movement management and MOTOZOOM motorized lens control.

Thanks to this technology, Dahua guarantees private individuals and installers a simple, low-cost installation with surprising results and added value in the field of video surveillance. Video security system ideal for a wide range of applications: from companies to public administrations, from parks to institutional offices, from museums to airports, from villas to small condominiums etc...

Specifications

• Supported CCTV Technological Standards: CVBS/HDCVI/HDTVI/AHD + IP@6Mpx (Max. 16 IP) Onvif 16.12
• Supported HDCVI resolutions: 1080N/720P@15fps, 960H/D1/CIF@25/30fps.
• Supported AHD resolution: 1080N/720P@15fps, 960H/D1/CIF@25/30fps.
• Supported HD-TVI resolution: 1080N/720P@15fps, 960H/D1/CIF@25/30fps.
• Video signal transmission over long distances (800-1100M), using coaxial cable.
• Management from XVR via coax cable. OSD menu and PTZ movement of cameras.
• Recording (REC & Live) on all channels in HD resolution 1080N/720@15fps
• H.265+/H.265/H.264+/H.264 & MJPEG dual-stream video compression.
• Simultaneous HDMI/VGA/BNC (SPOT) video output.
• 1/4/8/16/32 channels (IP extension not active) or 1/4/8/16/32/36 (IP extension active), GRID interface and intelligent search
• Dahua PTZ Dome Camera 3D Intelligent Positioning - RS485 Port for Classic Analog PTZ.
• Supports 1 Input + 1 RCA Audio Output. Microphone input and output capability (Two-way talk).
• Supports 2 SATA HDD up to 10TB, 2 USB ports (2.0)
• Multiple network monitoring: Web viewer, CMS (DSS / Smart PSS) Smartphone (DMSS).
• New simplified and intelligent graphic interface (version 4.0); with Smart Fan / Coax. Audio functions.
• Easy setup P2P QR scan with dedicated Dahua Cloud service.
• ONVIF Version 16.12 Compliant, CGI Conformant
