Dahua DVR 16 Channels 4K 8 Mpx Poc Hybrid Cloud Ahd IP Hard Disk 1 TB

DAHUA DVR 16 CHANNELS 4K 8 MPX POC HYBRID CLOUD AHD IP HARD DISK 1 TB

PoC, which stands for Power over Coax, transmits both video and power over a single coaxial cable. By eliminating power cables, HDCVI PoC technology further simplifies system installation, reducing operating costs.

• Affordability: High performance at an incredibly attractive price.
• SMD: Effectively filters false alarms and enables quick target search.
• H.265+/H.265: Optimized encoding for greater efficiency.
• Extended Range: 400 meters for 1080P cameras and 300 meters for 4MP cameras.
• All about Coax: Audio, alarms and firmware updates over coax cable.

DATASHEET Dahua XVR5216AN-4KL-X-16P

• Video Compression: H.265+/H.265/H.264+/H.264
• Audio Compression: AAC/G.711/PCM
• Video Standard: HDCVI/AHD/CVBS/TVI (Auto-detect)
• Max. Recording Resolution : CH01-16: 4K
• Max recording rate: 10fps@4K 10fps@6MP – 12fps@5MP,15fps@4MP – 15fps@3MP, – 30fps@4M-N – 30fps@1080P
• CVBS Input: 16 CH,1.0Vp-p,75Ω
• IP Camera Input: 16+8 Up to 8 Mp
• Max IP Input/Record: 96Mbps/96Mbps
• Audio In/Out: 1/1, Bidirectional
• Display: HDMI(3840×2160) – VGA(1920×1080), TV
• Max HDD: 2×10TB
• eSATA: No
• USB: 1 USB3.0, 1 USB2.0
• DVD Burner: USB
• In/Out Alarm: No
• Ethernet: 1 Gigabit port
• Remote User Logins: 128
• Dimensions: 375×287×53 mm
• Power supply: DC54V, ≤20W (Without HDD)
• Video Analysis: Tripwire, Intrusion, Abandoned/Missing, Face Detection
• Other Functions: P2P, Coaxial Audio/Alarm/Upgrade, 2D/3DNR
